Neurons in the brain communicate via rapid electrical impulses that allow the brain to coordinate behavior, sensation, thoughts, and emotion. Scientists who want to study this electrical activity usually measure these signals with electrodes inserted into the brain, a task that is notoriously difficult and time-consuming.

MIT researchers have developed a light-sensitive protein that can be embedded into neuron membranes, where it emits a fluorescent signal that indicates how much voltage a particular cell is experiencing. This could allow scientists to study how neurons behave, millisecond by millisecond, as the brain performs a particular function. (Image courtesy of the researchers)

MIT researchers have now come up with a completely different approach, which they believe will prove much easier and more informative. They have developed a light-sensitive protein that can be embedded into neuron membranes, where it emits a fluorescent signal that indicates how much voltage a particular cell is experiencing. This could allow scientists to study how neurons behave, millisecond by millisecond, as the brain performs a particular function.

If you put an electrode in the brain, it’s like trying to understand a phone conversation by hearing only one person talk, but with this method, you can record the neural activity of many cells in a neural circuit and hear them as they talk to each other.

For the past two decades, scientists have sought a way to monitor electrical activity in the brain through imaging instead of recording with electrodes. Finding fluorescent molecules that can be used for this kind of imaging has been difficult; not only do the proteins have to be very sensitive to changes in voltage, they must also respond quickly and be resistant to photobleaching (fading that can be caused by exposure to light).

The researchers came up with a new strategy for finding a molecule that would fulfill everything on this wish list: They built a robot that could screen millions of proteins, generated through a process called directed protein evolution, for the traits they wanted. They essentially imitated the process by which evolution works in nature: take a gene, make millions and millions of mutant genes, and finally pick the ones that work the best.

The researchers made 1.5 million mutated versions of a light-sensitive protein called QuasAr2, which was previously engineered at Harvard University. They put each of those genes into mammalian cells (one mutant per cell), then grew the cells in lab dishes and used an automated microscope to take their pictures. The robot was able to identify cells with proteins that met the criteria the researchers were looking for, the most important being the protein’s location within the cell and its brightness. The team then selected five of the best candidates and did another round of mutation, generating 8 million new candidates. The robot picked out the seven best of these, which the researchers then narrowed down to one top performer, which they called Archon1.

A key feature of Archon1 is that once the gene is delivered into a cell, the protein embeds itself into the cell membrane, which is the best place to obtain an accurate measurement of a cell’s voltage. Using this protein, the researchers were able to measure electrical activity in mouse brain tissue, as well as in brain cells of zebrafish larvae, and the worm Caenorhabditis elegans. The latter two organisms are transparent, so it is easy to expose them to light and image the resulting fluorescence. When the cells are exposed to a certain wavelength of reddish-orange light, the protein sensor emits a longer wavelength of red light, and the brightness of the light corresponds to the voltage of that cell at a given moment in time.

The researchers also showed that Archon1 can be used in conjunction with light-sensitive proteins that are commonly used to silence or stimulate neuron activity — optogenetic proteins — as long as those proteins respond to colors other than red. In experiments with C. elegans, they demonstrated that they could stimulate one neuron using blue light and then use Archon1 to measure the resulting effect in neurons that receive input from that cell.

Currently, the work using this technology is to measure brain activity in mice as they perform various tasks, which the researchers believe should allow them to map neural circuits and discover how they produce specific behaviors.
