A driverless car is making its way through a winding neighborhood street, about to make a sharp turn onto a road where a child’s ball has just rolled. Although no person in the car can see that ball, the car stops to avoid it. This is because the car is outfitted with extremely sensitive laser technology that reflects off nearby objects to see around corners.

This scenario is one of many that researchers at Stanford University are imagining for a system that can produce images of objects hidden from view. They are focused on applications for autonomous vehicles, some of which already have similar laser-based systems for detecting objects around the car, but other uses could include seeing through foliage from aerial vehicles or giving rescue teams the ability to find people blocked from view by walls and rubble.

The Stanford group isn’t alone in developing methods for bouncing lasers around corners to capture images of objects. Where this research advances the field is in the extremely efficient and effective algorithm the researchers developed to process the final image. For their system, the researchers set a laser next to a highly sensitive photon detector, which can record even a single particle of light. They shoot pulses of laser light at a wall and, invisible to the human eye, those pulses bounce off objects around the corner and bounce back to the wall and to the detector. Currently, this scan can take from two minutes to an hour, depending on conditions such as lighting and the reflectivity of the hidden object. Once the scan is finished, the algorithm untangles the paths of the captured photons and, like the mythical image enhancement technology of television crime shows, the blurry blob takes much sharper form. It does all this in less than a second and is so efficient it can run on a regular laptop. Based on how well the algorithm currently works, the researchers think they could speed it up so that it is nearly instantaneous once the scan is complete.

Graduate student David Lindell and Matt O’Toole, a post-doctoral scholar, at work in their lab. (Image courtesy of L.A. Cicero)

The team is continuing to work on this system so it can better handle the variability of the real world and complete the scan more quickly. For example, the distance to the object and amount of ambient light can make it difficult for their technology to see the light particles it needs in order to resolve out-of-sight objects. This technique also depends on analyzing scattered light particles that are intentionally ignored by guidance systems currently in cars — known as LIDAR systems. Although the team believes their algorithm is ready for LIDAR systems, the key question is whether the current LIDAR hardware can support this type of imaging.

Before the system is road ready, it will also have to work better in daylight and with objects in motion, like a bouncing ball or running child. The researchers did successfully test their technique outside, but they worked only with indirect light. Their technology performed particularly well picking out retroreflective objects, such as safety apparel or traffic signs. The researchers say that if the technology were placed on a car today, that car could easily detect things like road signs, safety vests, or road markers, although it might struggle with a person wearing non-reflective clothing.
