Stanford and Seoul National University researchers have developed an artificial sensory nerve system that can activate the twitch reflex in a cockroach and identify letters in the Braille alphabet. The work, reported May 31 in Science, is a step toward creating artificial skin for prosthetic limbs, to restore sensation to amputees, and perhaps one day give robots some type of reflex capability. According to the researchers, skin is a complex sensing, signaling, and decision-making system. This new artificial sensory nerve system is a step toward making skin-like sensory neural networks for all sorts of applications.

This milestone is part of the quest to mimic how skin can stretch, repair itself, and most remarkably, act like a smart sensory network that knows not only how to transmit pleasant sensations to the brain, but also when to order the muscles to react reflexively to make prompt decisions.

Stanford Professor Zhenan Bao is leading American and Korean researchers in the quest for an artificial nerve system. (Image courtesy of Kevin Craft)

The new Science paper describes how the researchers constructed an artificial sensory nerve circuit that could be embedded in a future skin-like covering for neuro-prosthetic devices and soft robotics. This rudimentary artificial nerve circuit integrates three previously described components. The first is a touch sensor that can detect even minuscule forces. This sensor sends signals through the second component — a flexible electronic neuron. The touch sensor and electronic neuron are improved versions of inventions previously reported by the laboratory of Professor Zhenan Bao at Stanford. Sensory signals from these components stimulate the third component, an artificial synaptic transistor modeled after human synapses. The synaptic transistor is the brainchild of Tae-Woo Lee of Seoul National University, who spent his sabbatical year in Bao's lab to initiate the collaborative work.

According to Lee, biological synapses can relay signals, and also store information to make simple decisions. The synaptic transistor performs these functions in the artificial nerve circuit. He used a knee reflex as an example of how more-advanced artificial nerve circuits might one day be part of an artificial skin that would give prosthetic devices or robots both senses and reflexes.

In humans, when a sudden tap causes the knee muscles to stretch, certain sensors in those muscles send an impulse through a neuron. The neuron in turn sends a series of signals to the relevant synapses. The synaptic network recognizes the pattern of the sudden stretch and emits two signals simultaneously, one causing the knee muscles to contract reflexively and a second, less urgent signal to register the sensation in the brain.

The new work has a long way to go before it reaches that level of complexity. But in the Science paper, the group describes how the electronic neuron delivered signals to the synaptic transistor, which was engineered in such a way that it learned to recognize and react to sensory inputs based on the intensity and frequency of low-power signals, just like a biological synapse. The group tested the ability of the system to both generate reflexes and sense touch. In one test they hooked up their artificial nerve to a cockroach leg and applied tiny increments of pressure to their touch sensor. The electronic neuron converted the sensor output into digital signals and relayed them through the synaptic transistor, causing the leg to twitch more or less vigorously as the pressure on the touch sensor increased or decreased.

They also showed that the artificial nerve could detect various touch sensations. In one experiment it was able to differentiate Braille letters. In another, they rolled a cylinder over the sensor in different directions and accurately detected the direction of the motion.

The researchers say artificial nerve technology remains in its infancy. For instance, creating artificial skin coverings for prosthetic devices will require new devices to detect heat and other sensations, the ability to embed them into flexible circuits, and then a way to interface all of this to the brain.

They also hope to create low-power, artificial sensor nets to cover robots, the idea being to make them more agile by providing some of the same feedback that humans derive from their skin.
