Sometimes referred to as “solid smoke,” aerogels are the world’s lightest solid materials, composed of approximately 85% air by volume. Polyamide aerogels open up a whole new world of applications due to their unique properties: translucent like silica aerogels, thermoplastic, ultra-low density, superior mechanical properties, low-temperature operating range, and highly flexible (as compared to NASA Glenn’s polyimide aerogels). Polyamide aerogels are further novel because of their tunable glass transition temperatures, meaning that crystallinity — and hence strength — can be controlled via operating temperature. Addressing the key drawbacks of aerogel technology (hydroscopicity, fragility, cost), NASA Glenn’s suite of organic aerogels is cost-competitive with both existing silica aerogels and, with scale-up, high-end foamed polymer insulation. Finally, Glenn’s materials are truly multi-functional — they can be structural members while providing superior thermal properties and extremely low dielectric (near that of air).

Polyamide aerogels are translucent, thermoplastic, have ultra-low density, exhibit superior mechanical properties, have a low-temperature operating range, and offer high flexibility.

Polyamides are polymers that are similar to polyimides (another polymer that has been developed for use in aerogels). However, because the amide link is a single chain while the imide link is a ring structure, polyamide aerogels can be made less stiff than polyimides, even though a similar fabrication process is used. The precursor materials can be made from any combination of diamine and diacid chloride. Furthermore, NASA Glenn researchers have found methods for using combinations of diamines and disecondary amines to produce polyamide aerogels with tunable glass transition temperatures for greater control of features such as flexibility or water-resistance.

In the first step of the fabrication process, an oligomeric solution is produced that is stable and that can be prepared and stored indefinitely as stock solutions prior to cross-linking. This unique feature allows for the preparation and transport of tailor-made polyamide solutions that can later be turned into gels via the addition of a small amount of cross-linker. When the cross-linking agent is added, the solution can be cast in a variety of forms, such as thin films and monoliths. To remove the solvent, one or more solvent exchanges can be performed, and then the gel is subjected to supercritical drying to form a polyamide aerogel. NASA Glenn’s polyamide aerogels can be fully integrated with the fabrication techniques and products of polyimide aerogel fabrication, so hybrid materials that have the properties of both classes are easily prepared. As the first aerogels to be composed of cross-linked polyamides, these materials combine flexibility and transparency in a way that sets them apart from all other polymeric aerogels.

Applications for this technology include construction, garments, appliances, and camping gear.

NASA is actively seeking licensees to commercialize this technology. Please contact the Technology Transfer Office at This email address is being protected from spambots. You need JavaScript enabled to view it. to initiate licensing discussions. Follow this link for more information: http://technology.nasa.gov/patent/TB2016/LEW-TOPS-31.
