While invisible to the human eye, UV rays surround us in our environment, and excessive exposure can cause health issues including skin cancer and premature skin aging. The intensity of UV rays is typically reported through an index during weather reports. A wearable device, such as a T-shirt or watch that monitors the actual personal UV exposure throughout the day, would be a useful and more accurate guide for people seeking to avoid sun damage.

NTU researchers have reported that their flexible UV light sensors were 25 times more responsive, and 330 times more sensitive than existing sensors, exceeding the performance level required for optoelectronic applications — light-based electronics.

UV light sensors, also known as photodetectors, are used in a wide range of systems, from smartphones to biomedical imaging. Over the past decades, gallium nitride (GaN) has gained prominence as the ideal material to fabricate UV light sensors, largely due to its superior properties in emitting, regulating, transmitting, and sensing light. However, most GaN-based UV sensors today are built on rigid layers, limiting their use in flexible and wearable products.

While researchers elsewhere have developed flexible GaN-based UV sensors, they have not attained the level of performance required for state-of-the-art use. Two of their biggest challenges are low responsivity and low sensitivity. The NTU team overcame these constraints by creating flexible UV light sensors on a semiconductor wafer 8 inches in diameter, using free-standing single-crystalline layers of GaN and aluminum gallium nitride (AlGaN), arranged using membranes that consist of two different thin semiconductor layers (heterostructure membranes).

This type of semiconductor structure, which can be fabricated using existing industrial-compatible methods, allows the material to be easily bent, making it ideal for use in flexible sensors. At the same time, the chemical composition of the material changes with depth, meaning that high performance is maintained even when it comes under strain.

In lab tests, the NTU flexible UV light sensors operated at high levels of responsivity and sensitivity even while being subjected to multiple bending and high temperature tests. Under a range of external strains (compressive, flat, and tensile), the sensors recorded a responsivity level of between 529 – 1340 Ampere/Watt (unit used to measure the ability of a device to convert an optical signal to an electrical signal), which is about 100 times higher than existing UV sensors. This responsivity remained stable after 100 cycles of repetitive bending, demonstrating its potential to be integrated into wearables.

“The high-performance flexible UV light sensors we have created pave the way forward for a wide range of future wearable applications, such as in personal smart health monitoring, where people can accurately measure their UV exposure levels throughout the day to reduce their risk of skin cancer,” said Professor Kim Munho. Skin cancer, one of the most common types of cancer globally, is primarily caused by overexposure to UV radiation from the sun. In regions such as Australia, which has the highest rate of skin cancer in the world, it is estimated that approximately 2 in 3 people will be diagnosed with skin cancer by the time they reach the age of 70, according to data compiled by the World Cancer Research Fund.

“Skin cancer can be prevented by protecting the skin from excessive sun exposure. So, a reliable wearable device that could track UV exposure could be a handy tool to help monitor one's recommended exposure, particularly for those who spend a lot of time outdoors,” the research team said.

For more information, contact This email address is being protected from spambots. You need JavaScript enabled to view it..
