Product of the Month

Harwin, Salem, NH, announced the SYCAMORE surface-mount socket that provides pin retention and durability for high-volume applications manufactured using automated systems. The capacitor's design features three points of contact, providing continuity and robustness. Key markets include gas detection systems, metering systems, and other applications that require modules and devices such as field-replaceable parts or temperature-sensitive components to be mounted to a printed circuit board. The single-part SMT socket design features a profile of 0.3 mm above the PCB. Available in top and bottom entry versions, it accepts 1.0 or 1.50 mm-diameter pins, and is open-ended for unlimited mating pin depth. It is manufactured from beryllium copper, and contacts are gold-plated to ensure high conductivity over a temperature range of -50 to +125 °C.
