Worldwide, glass manufacturing produces at least 86 million tons of carbon dioxide (CO 2) every year. A new type of glass aims to cut this carbon footprint in half. The invention — LionGlass, engineered at Penn State — requires significantly less energy to produce and is much more damage resistant than standard soda lime silicate glass.
“Our goal is to make glass manufacturing sustainable for the long term,” said Professor and lead researcher John Mauro. “LionGlass eliminates the use of carbon-containing batch materials and significantly lowers the melting temperature of glass.”
Soda lime silicate glass, the common glass used in everyday items from windows to glass tableware, is made by melting three primary materials: quartz sand, soda ash, and limestone. Soda ash is sodium carbonate and limestone is calcium carbonate, both of which release CO2 as they are melted.
“During the glass-melting process, the carbonates decompose into oxides and produce carbon dioxide, which gets released into the atmosphere,” Mauro said.
But the bulk of the CO2 emissions come from the energy required to heat furnaces to the high temperatures needed for melting glass. With LionGlass, the melting temperatures are lowered by about 300 °C to 400 °C, Mauro explained, which leads to a roughly 30 percent reduction in energy consumption compared to conventional soda lime glass.
Not only is LionGlass easier on the environment, but it also possesses significantly higher crack resistance compared to conventional glass.
“We kept increasing the weight on LionGlass until we reached the maximum load the equipment will allow,” said Nick Clark. “It simply wouldn’t crack.”
“Damage resistance is a particularly important property for glass,” Mauro said. “Think about all the ways we rely on the strength of glass, in the automotive industry and electronics industry, architecture, and communication technology like fiber-optic cables. Even in health care, vaccines are stored in strong, chemically resistant glass packaging.”
“We should be able to reduce the thickness and still get the same level of damage resistance,” Mauro said. “If we have a lighter-weight product, that is even better for the environment, because we use less raw materials and need less energy to produce it. Even downstream, for transportation, that reduces the energy required to transport the glass, so it’s a winning situation for everyone.”
Mauro noted that the researchers are still evaluating the potential of LionGlass. They have filed a patent application for the entire family of glass, which means there are many compositions within the LionGlass family. They are now in the process of exposing various compositions of LionGlass to an array of chemical environments to study how it reacts. The results will help the team develop a better understanding of how LionGlass can be used throughout the world.
“Humans learned how to manufacture glass more than 5,000 years ago, and since then it has been critical to bringing modern civilization to where it is today,” Mauro said. “Now, we are at a point in time when we need it to help shape the future, as we face global challenges such as environmental issues, renewable energy, energy efficiency, health care, and urban development. Glass can play a vital role in solving these issues, and we are ready to contribute.”
