Products: Imaging
Gigabit Ethernet Cameras

Baumer, Southington, CT, has introduced the TXG series of Gigabit Ethernet cameras designed to provide Power over Gigabit Ethernet, eliminating the need for a separate power cable. The cameras are designed for vision...

Extech Instruments, Waltham, MA, has introduced the Model RPM10 photo/contact tachometer that includes a built-in, noncontact infrared thermometer with laser pointer that provides surface...

Products: Robotics, Automation & Control
Accelerometer

The KXTE9 accelerometer from Kionix (Ithaca, NY) has embedded algorithms for orientation and activity monitoring. The algorithms simplify the adoption of motion-based functionality in consumer electronics, while reducing...

Products: Robotics, Automation & Control
Optical Encoder

The TONIC optical encoder from Renishaw (Hoffman Estates, IL) packs advanced optics and electronics into a compact read-head measuring 35 × 13.5 × 10 mm. Available in both linear and rotary versions, it supports...

Products: Robotics, Automation & Control
24Vdc Gearmotor

The Model No. MMP-TM55-24V GP52-059 dc gearmotor from Midwest Motion Products (Watertown, MN) produces 60in.-lb. of torque at 78 rpm. Designed to operate on 24 Vdc, it measures 2.14in. diameter × 7.75in. long, and has a...

Products: Robotics, Automation & Control
Ball Valve

A miniature ball valve from Beswich Engineering (Greenland, NH) comes in two configurations. The MBV-1010-303 is for applications requiring an on/off valve, while the MBVT-1010-303 is for applications requiring selecting one of...

Products: Robotics, Automation & Control
Hydraulic Power Pack

The KA power pack from HAWE Hydraulics (Charlotte, NC) can supply pressure up to 10,000 psi utilizing a radial piston pump, or up to 2,900 psi utilizing a gear pump.

Products: Robotics, Automation & Control
Servo Motors

The SM2315D-PLS2 and SM2315DT-PLS2 integrated servo motors from Animatics Corp. (Santa Clara, CA) have a built-in controller, encoder, and amplifier, and can be programmed to control several machines. They achieve resolution up...

Products: Robotics, Automation & Control
Clean Room Motor

The Clean Motors from HaydonKerk Motion Solutions (Waterbury, CT) are designed to limit contaminants and outgassing in vacuum environments. The motors operate in vacuum down to 10-9 Torr.

Products: Robotics, Automation & Control
Micro Manipulator

The MT 105-50-LM micro manipulator stage from Steinmeyer (Burlington, MA) provides a positional accuracy of 1 micrometer, straightness/flatness runout of +/1 micrometer, and repeatability of +/0.2 micrometers. It...

Products: Robotics, Automation & Control
Position Sensor

The TRACKER TRK-1TO2 position sensor from New Scale Technologies (Victor, NY) measures 8.5 × 11.5 × 1.61 mm and provides 2-micrometer resolution. It can be used as a linear encoder or off-axis rotary encoder and unlike...

Products: Robotics, Automation & Control
Voice Coil Actuators

A family of linear voice coil actuators from BEI Kimco Magnetics (Vista, CA) include two spring designs based on magnetic rather than mechanical technology. This technology ensures constant and precise valve position in...

Products: Robotics, Automation & Control
Choke Coil

The CM01H900 common-mode choke coil from Taiyo Yuden (U.S.A.) Inc. (Schaumburg, IL) measures 1.2(L) × 1.0(W) × 0.9(H) mm, reportedly the industry’s smallest. The coil’s common-mode impedance is 65 ohms at 100 MHz.

Products: Robotics, Automation & Control
Integrated Motor/Drive

The MDrive14Plus Microstepping and MDrive14Plus Half/Full Step motor/drives from Intelligent Motion Systems (Marlborough, CT) use a NEMA size 14 brushless 1.8in. stepping motor and measure just 1.9 × 1.4 × 2.0 in....

Products: Robotics, Automation & Control
Rod Clamp

The AMLOK(R) Hydraulic Series RCH Rod Clamp from Advanced Machine & Engineering (Rockford, IL) is designed to clamp components after the motion has stopped and to hold the position securely as long as the forces do not exceed...

Products: Robotics, Automation & Control
Smart Motor Controller

The AH5792 smart motor controller from Diodes Inc. (Hauppauge, NY) integrates a Hall sensor and amplifier, complete digital circuitry, and a full bridge output driver in an SOT553 package. These features eliminate...

Products: Robotics, Automation & Control
Nano Positioner

The Nano-SP30 positioning system from Mad City Labs (Madison, WI) is suited for nano-indentation and nano manipulation applications. It provides 25mm of travel with a step size of 95nm. A piezo-driven stage achieves...

Products: Robotics, Automation & Control
Robotic Gripper

The LEG long-stroke electric gripper from SCHUNK Inc. (Morrisville, NC) weighs only 8.8 kg. When operated with a single servomotor, it delivers a gripping force of 1140 N and a variable stroke from zero to 568 mm. The gripper...

Products: Robotics, Automation & Control
Oxygen Flow Meter

The Oxyview™ polycarbonate oxygen flow meter from Qosina provides in-line monitoring of oxygen levels from 1 to 6 liters/minute. The flow meter can connect close to the patient in any orientation, providing an advantage...

Products: Robotics, Automation & Control
Servo Coupling

R+W (Bensenville, Il) has developed a series of couplings for mounting to flange output servo gearheads, The BK8 coupling allows for an equally compact flexible interface between gearheads and driven components, protecting...

Products: Robotics, Automation & Control
Servo Motor Control

The ADAM-5240 from the Industrial Automation Group of Advantech (Cincinnati, OH) is a 4-axis stepping/ pulse-type servo motor control module for use with the ADAM-5550 series PACs (Programmable Automation Controllers)....

Products: Robotics, Automation & Control
Bearing Monitoring Module

The 750-645 2-channel vibration and roller bearing monitoring module from WAGO Corp. (Germantown, WI) tracks machine vibration conditions. Based on ISO’s 10816-3 mechanical vibration standard, it monitors and...

Products: Robotics, Automation & Control
Motion Card

The Prodigy family of motion cards from Performance Motion Devices Inc. (Lincoln, MA) now gives machine designers the capability to download and run motion programs. This capability off-loads the PC host and increases the...

Products: Robotics, Automation & Control
AC Gearmotor

The VWDIR20 AC gearmotors from Bison Gear & Engineering Corp. (St. Charles, IL) are rated 1/4 hp (186 watts) at 115V, 60 Hz. The compact, integral gear reducers feature a phenolic high speed gear for low noise and steel...

Products: Robotics, Automation & Control
Linear Drive System

The RPS4014 linear drive system from Nexen (Vadnais Heights, MN) adds two rollers for a total of 14, and a wider rack to double thrust capacity of 14000 Nm. It is available in a standard grade with positional accuracy of...

Products: Photonics/Optics
Product of the Month: Infrared Camera

The ICI 7320 infrared camera from Infrared Cameras (Beaumont, TX) operates on 1 watt of power via USB connection. IR Flash software provides real time radiometric data stream directly to a hard drive or...

Products: Photonics/Optics
Large Format MWIR Lens

StingRay Optics (Keene, NH) introduces a 50mm, f/2.3 Midwave Infrared (MWIR) large format lens assembly. The 50mm lens offers flexibility as either a stand alone solution for large format detectors or in conjunction...

Products: Photonics/Optics
Light Measurement System

Labsphere (North Sutton, NH) offers the HalfMoon Total Forward Spectral Flux Measurement System designed for manufacturers of LEDs, light fixtures, and displays. Available in standard 12, 20, and 40 inch diameters,...

Products: Photonics/Optics
Optical Fibers and Cables

Fiberguide Industries (Stirling, NJ) offers single mode, multimode, graded index, tapered, and metal-coated optical fibers that are suitable for applications in the medical/biomedical and spectroscopy industries, as...
