Ethernet CCD Camera

The TM-1405GE from JAI PULNiX (San Jose, CA) is a high-resolution, 1.4-megapixel CCD camera. The interline transfer CCD permits full vertical and horizontal resolution with shutter speeds up to 1/16,000 sec. Asynchronous test, combined with a no-delay, pulse-width controlled shutter, provides flexible triggering and exposure...

Products
Pulsed Fiber Laser

Lumics (Berlin, Germany) has introduced the LU1060F400 pulsed fiber laser that offers up to 0.8 mJ pulse energy with average power of 4W. It is a short-pulse Ytterbium fiber laser in Master Oscillator Power Amplifier (MOPA) configuration. The laser operation mode can be changed by selecting customer-specific parameters, such...

Products
Image Analysis Software

Sensors Unlimited, Goodrich Corp. (Princeton, NJ) has released SUI Image Analysis Software, which allows full operational control of the high-speed windowing functions on the SU320MSW-1.7RT Shortwave Infrared (SWIR) Windowed Snapshot MiniCamera, and the SU640SDWH-1.7RT High-Resolution SWIR Windowing Camera. The...

Products
DA-130 ruggedized notebook computer

Dewetron, Charlestown, RI, has introduced the DA-130 ruggedized notebook computer that includes the company's proprietary SideHAND® battery power system, allowing it to run indefinitely without any external power source. Batteries are hot-swappable, and can be exchanged even when the system is running off...

Products
Product of the Month: Camera Shutters

Melles Griot Optics Group (Rochester, NY) has released the ExtremeService™ shutter designed for operation in environmental conditions involving variations in temperature. The shutter is suitable for OEM applications including night vision cameras and infrared illumination systems such as analytical,...

Products
Fiber-Optic Laser Couplers

Bristol Instruments (Victor, NY) offers the LC Series fiber-optic laser couplers that can be used to launch a free-space laser beam into a fiber, or return the laser to a collimated free-space beam. The couplers contain a 1"- diameter mounting disk attached to 3 meters of 9-μm core-diameter fiber that is terminated...

Products
Wide-Gap Sensor

TT Electronics OPTEK Technology (Carrollton, TX) offers the OPB856Z Series wide-gap optical sensor that includes an emitter-sensor pair. The sensor consists of an LED and a phototransistor designed to operate over distances of 12" in industrial environments. The sensor components are mounted in threaded, color-coded housings; the...

Products
Laser Processing System

Universal Laser Systems (Scottsdale, AZ) has added a laser platform to its XL Series of industrial CO2 laser processing systems that can provide 400 watts of air-cooled laser power. The laser utilizes direct air-cooling, eliminating the need for chillers and plumbing. Two models are available: the XL-9200...

Products
FBG Sensor Arrays

QPS Photronics (Montreal, QE, Canada) offers sensor arrays with 100 Fiber Bragg Gratings (FBGs) in each array, with the total length of the fiber measuring 20 kilometers. Through a front-end switch matrix, 16 of these fiber arrays can be connected together to form a Star Network that contains a total of 1,600 sensors. This...

Products
CCD Camera

A custom CCD camera capable of operating at 100 million frames per second is available from KAMAN Electro-Optics Dev. Center (Tucson, AZ). The camera’s 10-nsec exposures offer speed-of-light image capture outside the gated-ICCD realm. The units are available as 64 × 64 format with 16-frame burst capability. Individual frame...

Products
UV Hazard Meter

The X1-1 + XD-9506-4 UV hazard meter and detector from Gigahertz- Optik (Newburyport, MA) can operate and display separate UV-C/B and UV-A detector measurements, and can calculate and display the sum of the two detector readings for UV hazard assessment. The XD-9506 detector covers the ACGIH/ICNIRP UV spectral guidelines by...

Products
Imaging Camera

PerkinElmer Optoelectronics (Fremont, CA) has introduced the MultiBlue™ multi-purpose CCD imaging camera featuring 12-bit output depth and USB 2.0 and IEEE-1394b FireWire interfaces that provide dual plug-and-play connectivity. The camera is Windows XP-compatible, and includes an Eastman Kodak KAI-0340SM imager with a pixel...

Products
Laser Event Recorder

OPTRA (Topsfield, MA) offers a laser event recorder that measures, characterizes, and documents laser exposures in support of dosimetry requirements for the protection of personnel working with, or who could potentially be exposed to, laser illumination. The laser event recorder is battery powered and operates for six hours...

Products
Crystal Rotation Stage

Cleveland Crystals (Highland Heights, OH) has introduced the CRS150 counter rotation stage that can facilitate simultaneous angle-tuning of two crystals oriented for compensation of birefringent walkoff. The walkoff compensation configuration provides nonlinear optical conversion, reduces distortion, and minimizes beam...

Products
Document Camera

The TT-02 from ELMO USA Corp. (Plainview, NY) is an XGA-output Visual Presenter that enables users to share information, documents, and small 3D objects with audiences. The camera contains a 5.3× optical zoom, 8× digital zoom, and one-touch auto focus. It features an 850,000-pixel scan CCD for reproduction of full-size A3...

Products
Optical Flats

Optical Surfaces (Surrey, UK) offers standard and custom optical flats measuring up to 600 mm in diameter and manufactured of materials such as glass, Zerodur, and silica. The optical flats can be used for measuring surface flatness of polished areas by determining the variations between work surfaces and the surface of the optical...

Products
CMOS Camera

Lumenera Corp. (Ottawa, ON, Canada) has introduced the Lw290, a USB 2.0 digital camera based on the company’s 1080P HD sensor. The 16:9 HD format, 2.0-megapixel CMOS sensor provides 20 frames per second at full 1920×1080 resolution. Higher frame rates are available at lower resolution, with full sub-window control and live...

Products
Diode Laser Platform

Spectra-Physics, a Division of Newport Corp. (Tucson, AZ), has released a 900- to 980-nm diode laser platform based on epitaxial design. The diode laser platform provides CW power conversion efficiency to 71% for 940-nm single emitters (15°C case temperature). More than 68.5% peak PCE at 25°C may be achieved from...

Products
USB-3101 analog data output device

NMeasurement Computing, Norton, MA, has released the USB-3101 analog data output device that is fully compatible with USB 1.1 and 2.0 ports. The full-speed device is supported under Microsoft(r) Windows(r) operating systems and provides four channels of analog voltage output, eight digital I/O connectors, and...

Products : Motion Control
Diaphragm Pumps

Thomas Products Div. (Sheboygan, WI) offers the Series 5002 miniature diaphragm liquid pumps, designed for all-liquid or mixed wet/dry pumping applications. Model 5002F pumps are single-head and measure 1.99 × 1.18 × 3.19". Model 5002FZ pumps are 1.99 × 1.18 × 4.88" and have twin heads. Both are oil-less. Standard materials...

Products : Motion Control
Motor Driver

Allegro MicroSystems (Worcester, MA) has introduced the A3901 dual H-bridge low-voltage motor driver. Capable of operating one stepper motor or two DC motors, the unit is designed for portable applications with a power-off current of 50 nA and an operating voltage range of 2.5 V to 5.5 V. MOSFET output stages reduce voltage drop and...

Products : Motion Control
Servo Drive Module

National Instruments (Austin, TX) has announced the NI 9505, a field-programmable gate array (FPGA)-based, H-bridge servo drive module for the NI CompactRIO embedded platform. The module offers direct connectivity to actuators such as fractional-horsepower brushed DC servo motors, relays, solenoids, lamps, and valves. A...

Products : Motion Control
Motor Controller

New Scale Technologies (Victor, NY) offers the SQ-2300 series benchtop motor controller for computer control of the company's SQUIGGLE motors and closed-loop linear nanopositioning stages. Using the controller, SQUIGGLE motor speed can vary continuously from micrometers per second to millimeters per second with better than...

Products : Motion Control
Anti-Backlash Nut

Haydon Switch & Instrument (Waterbury, CT) has released the “W” series of anti-backlash nuts, designed to minimize backlash between the leadscrew and nut interface. A blend of self-lubricating polyacetal and stainless steel screw material compensates for wear to avoid lock-ups. Available in a range of diameters and leads...

Products : Motion Control
Distance Measurement

The Acam-Messelectronic TDC-GPX chip from Transducers Direct (Miamiville, OH), allows distance measuring of ±1 mm rms to a range of 1,500 meters. The chip has four selectable operating modes: I-mode provides eight LVTTL input channels, a resolution of 81 picoseconds (ps), infinite measurement range, and 5.5 nanosecond (ns)...

Products : Motion Control
Multi-Axis Motion Control

Elmo Motion Control (Westford, MA) has unveiled its Maestro Multi-Axis Supervisor with firmware for support of the DS305 configuration protocol, DS401 CAN network IO integration protocol, and the DS402 motion control protocol. The Maestro is based on distributed motion control architecture and is now also integrated...

Products : Motion Control
Stepper Motor Controller

Nippon Pulse America (Radford, VA) has released the RoHS-compliant Motion Checker MCH-5, a palm-sized, standalone stepper motor controller with a built-in constant voltage driver. Front panel controls enable setting of rotation direction, speed control, position control, operation mode, stop time of the stepper motor,...

Products : Motion Control
Pneumatic Actuator

PHD (Fort Wayne, IN) has introduced the Series PLM pin locating clamp, a pneumatically powered actuator to locate, clamp, and support parts in welding applications. To protect against slag and other contaminants, the clamp is fully enclosed. A built-in locking mechanism fixes the pin in any position to secure parts if air...

Products
Pneumatic Valve

I&J Fisnar (Fair Lawn, NJ) has released the VMP30H multipurpose mini-poppet pneumatic valve designed for controlled dispensing of low to high viscosity materials such as silicone, epoxy, rubber adhesives, and greases. The poppet design minimizes surface area and friction between the valve and the material. A diaphragm located...

Products : Motion Control
Positioning System

The WCS2A/WCS3A PosiTrak™ Position Tracking System from Pepperl+Fuchs (Twinsburg, OH) consists of a U-shaped read head, a code rail and support hardware, and network and control interfaces. The read head optically scans a coded rail to determine a carrier mechanism's position. An internal microprocessor translates a 48...
