Measuring Instruments

A new technique from Massachusetts Institute of Technology researchers estimates material properties of physical objects, such as stiffness and weight, from video.

Space missions using magnetometers have been very successful. However, science missions now require higher levels of accuracy and stability in order to refine existing understanding and improve modeling. In most space missions that require high-accuracy vector measurement of magnetic fields, a separate scalar...

Molecular-based optical diagnostics techniques capable of obtaining simultaneous measurements of multiple fluid properties are critically important for characterizing hypersonic air-breathing engines, such as scramjet engines and scramjet-rocket combined cycle engines. Correlations between those...

Commercially available components are integrated into an assembly that can be used to measure the slosh dynamics of cryogenic liquids. The apparatus consists of a linear motion table that is properly instrumented to record high fidelity position, force, and acceleration measurements of all linear and rotation responses of...

A negative ion time projection chamber (NI-TPC) was developed that is suitable for measuring the polarization of bright transient events. The polarization of the astrophysical source is determined by imaging photoelectron tracks...

AROMA uses a boundary-element formulation to calculate normal and shear pressure distributions and sub-surface stresses for elastic bodies in contact. In addition to handling static normal and sheer loading, it also solves the contact problem for rolling elements such as bearings, traction drives, and...

Researchers from the University of California at Berkeley have created a thin, chameleon-like material that can be made to change color — on demand — by applying a minute amount of force.

This innovation is a tungsten-rhenium gauge that can be placed into an aft exit cone of a rocket motor. It will measure heat flux with time for the full duration of the RSRM (reusable solid rocket motor) nozzle environment with equal response time.

The magnetic sensitivity of a Ka-band isolator’s output phase is measured at 7 × 10–4 deg/G level. This high degree of precision is enabled by the sensitive phase measuring capabilities of a testbed built to mimic NASA’s Gravity Recovery and Interior Laboratory...

If selected for a NASA flight mission, the Ocean Radiometer for Carbon Assessment (ORCA) instrument will study microscopic phytoplankton, the tiny green plants that float in the upper layer of the ocean and make up the base of the marine food chain.
