Reversible, colorimetric fiber-optic sensors are undergoing development for use in measuring concentrations of ammonia in air at levels relevant to human health [0 to 50 parts per million (ppm)]. A sensor of this type includes an optical fiber that has been modified by replacing a portion of its cladding with a polymer...

A technique for detecting a small leak of gas into a vacuum involves the use of a diaphragm made of a thin film of poly (vinylidene fluoride) [PVDF]. To exploit the piezoelectricity of PVDF for this purpose, both sides of the film are coated with thin, electrically conductive layers that serve as...

This report investigates the strength of archi- tectural laminated glass and the viability of its use for window glass in commercial buildings. Some researchers recommend that the structural behavior of laminated glass (typically consisting of two glass layers and a plasticized PVB [polyvinyl...

A report discusses three designs of proposed low-power, zero-vibration coolers for infrared instruments planned to be flown aboard spacecraft to perform astrophysical observations far from Earth. The designs take advantage of the radiative precooling available in the projected deep-space operational...

A technical report enunciates the concept of a hierarchy of sensor classes (meaning transducers, associated circuitry, and embedded software) that have different levels of intelligence, and discusses issues pertaining to the development of sensors of the highest level of intelligence, called cognitive. The other...

A proposed method of characterizing microphones and other pressure and force sensors would exploit the temporally varying forces of impingement of amplitude-modulated light beams from inexpensive laser diodes. What makes the method likely to be practical is the surprising fact that these...

The Hydrogen Umbilical Mass Spectrometer (HUMS) consists of an integrated sample delivery system, a commercial mass-spectrometer- based gas analyzer, and a set of calibration gas mixtures traceable to NIST (National Institute for Standards and Technology). The system, except for the calibration gas...

The Hydrogen Umbilical Mass Spectrometer (HUMS) consists of an integrated sample delivery system, a commercial mass-spectrometer-based gas analyzer, and a set of calibration gas mixtures traceable to NIST (National Institute for Standards and Technology). The system, except for the calibration gas...

Miniature fiber-optic-coupled sensors based on optically excited, self-resonant microbeams have been proposed for measuring temperatures within muscle fascicles and tendons. The proposed sensors could be used in medical and biological research on humans and other animals. The proposed...

Some improvements have been made in the instrument described in "Instrument Records Magnetic Fields Generated by Lightning" (KSC-11769) NASA Tech Briefs, Vol. 19, No. 4 (April 1995), page 38. To conserve battery energy, the instrument was made to record the output of only one of three mutually...

Everybody creates models. These models are used to understand how products will hold up to the stresses, use, and abuse of real-world deployment; analyze the impact of design decisions on cost; simulate interactions; or evaluate numerous other metrics. Unfortunately, because of the variety of software...

An instrument that noninvasively measures alternating current over a broad frequency band (typically from about 0.3 to about 110 MHz) has been invented. This instrument could be especially useful for assessing radio-frequency hazards by measuring currents in various parts of humans or personnel...

Optoelectronic instruments for real-time, in situ monitoring of particle fallout are undergoing development. Settings in which these instruments could prove useful include clean rooms for assembly of optical and electronic equipment, food-packaging facilities, and other industrial facilities in...

A computer program enables the simultaneous monitoring and control of two commercial digital instrumentation recorders, each comprising a variable-rate buffer and a data tape recorder. The program can issue all standard tape-motion-related commands (fast forward, rewind, record, forward,...
