Electronics & Software

A computer program provides semiautomatic control of a moveable robot used to perform optical calibration of videocamera-based optoelectronic sensor systems that will be used to guide automated rendezvous maneuvers of spacecraft.

Control Panel is a computer program that generates a graphical user interface (GUI) for computational simulation of a rocket- test-stand propellant mixer in which gaseous hydrogen (GH2) is injected into flowing liquid hydrogen (LH2) to obtain a combined flow having desired thermodynamic...

A computer program implements a numerical model of thermal effects of cavitation in cryogenic fluids. The model and program were developed for use in designing and predicting the performances of turbopumps for cryogenic fluids. Prior numerical models used for this purpose do not account...

The RoseDoclet computer program extends the capability of Java doclet software to automatically synthesize Unified Modeling Language (UML) content from Java language source code. [Doclets are Java-language programs that use the doclet application programming interface (API) to specify the content and format of the output of...

FMG3D (full multigrid 3 dimensions) is a pilot computer program that solves equations of fluid flow using a finite difference representation on a structured grid. Infrastructure exists for three dimensions but the current implementation treats only two dimensions. Written in Fortran 90, FMG3D takes advantage of the...

Virtual Machine Language (VML) is a mission-independent, reusable software system for programming for spacecraft operations. Features of VML include a rich set of data types, named functions, parameters, IF and WHILE control structures, polymorphism, and on-the-fly creation of spacecraft commands from calculated values....

FWH2D is a Fortran 90 computer program that solves a two-dimensional (2D) version of the equation, derived by J. E. Ffowcs Williams and D. L. Hawkings, for sound generated by turbulent flow. FWH2D was developed especially for estimating noise generated by airflows around such approximately 2D...

AutoChem is a suite of Fortran 90 computer programs for the modeling of kinetic reaction systems. AutoChem performs automatic code generation, symbolic differentiation, analysis, and documentation. It produces a documented stand-alone system for the modeling and assimilation of atmospheric chemistry. Given databases of chemical reactions...

Some improvements have been made in the formulation of holographically formed polymer-dispersed liquid crystals (H-PDLCs) and in the fabrication of devices made from these materials, with resulting improvements in performance. H-PDLCs are essentially volume Bragg gratings. Devices made from HPDLCs function as...

The Modulation Sideband Technology for Absolute Range (MSTAR) architecture is the basis of design of a proposed laser-based heterodyne interferometer that could measure a range (distance) as great as 100 km with a precision and resolution of the order of 1 nm. Simple optical interferometers...

A method has been formulated to enable prediction of the amount of work that remains to be performed in developing flight software for a spacecraft. The basic concept embodied in the method is that of using an idealized curve (specifically, the Weibull function) to interpolate from (1) the...

A recently developed data-compression method is an adaptive technique for coding quantized wavelet-transformed data, nominally as part of a complete image-data compressor. Unlike some other approaches, this method admits a simple implementation and does not rely on the use of large code tables.

An algorithm analyzes rain-gauge data to identify statistical outliers that could be deemed to be erroneous readings. Heretofore, analyses of this type have been performed in burdensome manual procedures that have involved subjective judgements. Sometimes, the analyses have included...

NASA's Jet Propulsion Laboratory (JPL) generates planetary and lunar ephemeris data and FORTRAN routines that allow users to obtain state data for the Sun, the moon, and the planets. The JPL Solar System Ephemeris Toolbox, developed at Kennedy Space Center, is a set of functions that provides the same functionality in...

Major upgrades have been made in two of the programs reported in "Five Computer Codes for Analysis of Turbomachinery" (LEW-16851), NASA Tech Briefs, Vol. 23, No. 11 (November 1999), page 28. The affected programs are:

An end-of-life prediction system developed for electric machines and their loads could be used in integrated vehicle health monitoring at NASA and in other government agencies. This system will provide on-line, real-time condition assessment and end-of-life...

A computer program has been written to facilitate appraisals according to the methodology of Capability Maturity Model Integration (CMMI). [CMMI is a government/ industry standard, maintained by the Software Engineering Institute at Carnegie Mellon University, for objectively assessing the engineering capability...

Wing-Viewer is a computer program for acquisition and reduction of image data acquired by any of five different scientific grade commercial electronic cameras used at Langley Research center to observe wind-tunnel models coated with pressure or temperature-sensitive paints (PSP/TSP).

The Grid Visualization Tool (GVT) is a computer program for displaying the path of a mobile robotic explorer (rover) on a terrain map. The GVT reads a map-data file in either portable graymap (PGM) or portable pixmap (PPM) format, representing a gray-scale or color map image, respectively.

An updated version of the General Chemical Kinetics and Sensitivity Analysis (LSENS) computer code has become available. A prior version of LSENS was described in “Program Helps to Determine Chemical-Reaction Mechanisms” (LEW-15758), NASA Tech Briefs, Vol. 19, No. 5 (May 1995), page 66. To...

Avionics System Architecture Tool (ASAT) is a computer program intended for use during the avionics-system-architecture- design phase of the process of designing a spacecraft for a specific mission.

TURBO-AE is a computer code that enables detailed, highfidelity modeling of aeroelastic and unsteady aerodynamic characteristics for prediction of flutter, forced response, and bladerow interaction effects in turbomachinery.

The Portable Airborne Laser System (PALS) is a combination of laser ranging, video imaging, positioning, and data-processing subsystems designed for measuring the heights of forest canopies along linear transects from tens to thousands of kilometers long. Unlike prior laser ranging...
