The Miniature Variable-Speed Control Moment Gyroscope (MVS-CMG) was designed for small satellites (mass from less than 1 kg up to 500 kg). Currently available CMGs are too large and heavy, and available miniature CMGs do not provide sufficient control authority for use on practical satellites. This...

A document discusses a lightweight, functional mockup of the Pistol Grip Tool for use during underwater astronaut training. Previous training tools have caused shoulder injuries. This new version is more than 50 percent lighter [in water, weight is 2.4 lb (≈1.1 kg)], and can operate for...

The HEXPANDO is an expanding-head hexagonal wrench designed to retain fasteners and keep them from being dislodged from the tool. The tool is intended to remove or install socket-head cap screws (SHCSs) in remote, hard-to-reach locations or in circumstances when a dropped fastener...

Significant improvements have been made in the instrument originally described in a prior NASA Tech Briefs article: “Improved Speed and Functionality of a 580-GHz Imaging Radar” (NPO-45156), Vol. 34, No. 7 (July 2010), p. 51. First, the wideband YIG oscillator has been replaced...

The Interplanetary Overlay Networking Protocol Accelerator (IONAC) described previously in “The Interplanetary Overlay Networking Protocol Accelerator” (NPO-45584), NASA Tech Briefs, Vol. 32, No. 10, (October 2008) p. 106 provides functions that implement the Delay Tolerant Networking (DTN) bundle protocol. New missions that require...

This work describes the development of a large Ka Band Slot Array for the Glacier and Land Ice Surface Topography Interferometer (GLISTIN), a proposed spaceborne interferometric synthetic aperture radar for topographic mapping of ice sheets and glaciers. GLISTIN will collect ice...

This innovation can be run as a standalone network application on any computer in a networked environment. This design can be configured to control one or more routers (one instance per router), and can also be configured to listen to a policy server over the network to receive new...

HEMT-based receiver arrays with excellent noise and scalability are already starting to be manufactured at 100 GHz, but the advances in technology should make it possible to develop receiver modules with even greater operation frequency up to 200 GHz. A prototype...

Coupling between two waveguide-fed planar slot arrays has been investigated using full-wave analysis. The analysis employs the method-of-moments solution to the pertinent coupled integral equa- tions for the aperture electric field of all slots. In order to compute coupling between two arrays, the input...

A method has been designed for using multiple independent stations to discriminate fast transient radio sources from local anomalies, such as antenna noise or radio frequency interference (RFI). This can improve the sensitivity of incoherent detection for geographically separated stations such...

Break-out boxes (BOBs) are necessary for all electrical inte- gration/cable checkouts and troubleshooting. Because the price of a BOB is high, and no work can be done without one, often the procedure stops, simply waiting for a BOB. A less expensive BOB would take less time in the integration, testing, and troubleshooting...

The Remote Asynchronous Message Service (RAMS) gateway is a special-purpose AMS application node that enables exchange of AMS messages between nodes residing in different AMS “continua,” notionally in different geographical locations. JPL’s implementation of RAMS gateway functionality is integrated...

The MARSAUTOTIE program generates tie points for use with the Mars pointing correction software “In-Situ Pointing Correction and Rover Microlocalization,” (NPO-46696) Software Tech Briefs, Vol. 34, No. 9 (September 2010), page 18, in a completely automated manner, with no operator...

Jitter_Correct.m is a MATLAB function that automatically measures and corrects inter-frame jitter in an image sequence to a user-specified precision. In addition, the algorithm dynamically adjusts the image sample size to increase the accuracy of the measurement.
