Electronics & Software

Detection of low-level water clouds from space is one of the outstanding challenges in radar remote sensing. Spaceborne remote sensing is the only means of assessing the distribution and variability of cloud cover on a global basis. Uncertainties in models of the Earth’s heating budget will persist...

The Time Series Product Tool (TSPT) is a MATLAB-based software application that computes and displays high-quality vegetation and environmental monitoring indices from high temporal revisit rate Moderate resolution Imaging Spectroradiometer (MODIS) and other satellite sensors. The original purpose of the...

The test complexes at John C. Stennis Space Center (SSC) require reliable and accurate data acquisition in order to analyze the results of rocket engine tests. Acquisition systems include high-speed data, low-speed data, event monitoring, and video feeds. In order to obtain accurate data, routine calibrations...

This work demonstrated the cost-saving and fault-tolerant benefits of virtualization technology by consolidating the flight software from multiple flight processors into a single virtualized system. In this study, a flight software system that was originally deployed on six...

Traffic flow management (TFM) of the National Airspace System (NAS) endeavors to deliver flights from their origins to their destinations while minimizing delays and respecting all capacities. There are several models for solving this problem. Some models aggregate...

MCT enables users to compose software from objects that can be assembled by end users to create integrated functionality. Applications are eliminated in favor of compositions of “live objects” that can be combined in different ways for different users and missions as required, in contrast to the more...

The most common way to generate a rate-compatible family of codes is puncturing. In this method, one starts with a low-rate mother code and then selectively discards some of the coded bits to arrive at higher-rate codes. This approach is simple, but is not free of problems. Specifically, the mother...

Spacecraft display software is very costly and requires extensive testing and certification. Much testing must be repeated if the display software is changed in any way. Additionally, hand-coded displays are costly to create and maintain. For certain types of display formats with limited graphical...

The autonomous self-healing (eDNA) hardware platform is a reconfigurable field-programmable gate-array (FPGA)-type platform developed by Technical University of Denmark (patent: WO/2010/060923). It is capable of autonomously reconfiguring itself in case a fault is detected...

GPS receivers must compensate for the delay a GPS signal experiences as it passes through the ionosphere in order to accurately determine the position of the receiver. Receivers limited to terrestrial operation may utilize the Klobuchar parameters transmitted by...

Wafer-level integration was employed to mount the microshutter array for the James Webb Space Telescope (JWST) and the detector-read-out hybrid for TIRS (Thermal Infrared Sensor). In the case of the JWST substrate, two conductors (polysilicon and aluminum) separated by a silicon oxide...

A concept was developed for a multi-gigabit-rate, radiation-hardened (RH) bus that would support open-system architecture and provide a cost-effective, high-speed interconnect. This concept is based on Advanced Science and Novel Technology Company’s SerDes system, which supports a variety of interfaces, and...

As a result of performing IV&V (Independent Verification and Validation) on Space Station software, a number of interface faults were found during integrated testing or actual software deployment. Faults found at this late phase of the software development lifecycle are very expensive to...

Simple, Scalable, Script-based, Science Processing (S4P) Archive (S4PA) is a disk-based data-archiving system for remote sensing data. It is based on the data-driven framework of S4P. The system is used for new data transfer, data preprocessing, metadata generation, and data archival. The...

The Planetary Data System (PDS) has undertaken an effort to overhaul the PDS data architecture (e.g., data model, data structures, data dictionary, etc.) and deploy a software system (online data services, distributed data catalog, etc.) that fully embraces the PDS federation as an integrated...

ZONE (Zeroing Out Negative Effects) is a method of biofeedback training for optimal athletic performance. ZONE is designed to improve athletes’ responses to stress, anxiety, and loss of concentration during competition. In the training environment, when the user successfully attains an optimal...

In high-integrity systems, a method of assuring integrity called a self-checking pair is employed. A self-checking pair is a logical grouping of two of the same devices performing the same operation and cross-checking each other to ensure correct operation. In this manner, a...

The system and method of reconfigurable Auditory-Visual Display creates a multi-mode communications environment with the express intent of increasing situational awareness for the operator (controller), and for reducing operator fatigue. Situational awareness is increased by a...

Short block codes are in demand by international space agencies for transmission of command and control data to spacecraft in the uplink channel. Codes that outperform currently used binary codes with the same block lengths and code rates are desirable. A design method constructs...

A method has been developed for resolving algebraic loops that occur in closed-loop systems when using MathWorks Simulink modeling and simulation tools. This variable fidelity method improves accuracy and reduces runtime significantly for users of Simulink Coder...
