Mechanical & Fluid Systems

A lightweight, regenerable heat absorber (RHA), developed for rejecting metabolic heat from a space suit, may also be useful on Earth for short-term cooling of heavy protective garments. Unlike prior space-suit-cooling systems, a system that includes this RHA does not vent water. The closed system...

The deployable crew quarters (DCQ) have been designed for the International Space Station (ISS). Each DCQ would be a relatively inexpensive, deployable box-like structure that is designed to fit in a rack bay. It is to be occupied by one crewmember to provide privacy and sleeping functions for the crew. A DCQ comprises...

An enhanced version of the scheme reported in “Pseudo-Waypoint Guidance for Proximity Spacecraft Maneuvers” (NPO-42753), NASA Tech Briefs, Vol. 31, No. 6 (June 2007), page 73 was developed. To recapitulate: the scheme provides algorithms for guidance and control (G&C) of a...

A compression tool used to make 1-in. (2.5-cm) diameter disks of high-temperature polymers was designed to be shorter and of larger diameter than conventional tools to reduce heat loss to the surrounding air, thus making more efficient use of applied heat. This system is less sensitive to the amount and...

The design and testing of a structural system were implemented to hold the optics of the planned Space Interferometry Mission (SIM) at positions and orientations characterized by vibrational translation and rotation errors of no more than a few nanometers or a few milliarcseconds, respectively. Much of the...

A report discusses the methane and carbon monoxide/LOX (McLOx) rocket for ascent from Mars as well as other critical space propulsion tasks. The system offers a specific impulse over 370 s — roughly 50 s higher than existing space-storable bio- propellants. Current Mars in-situ propellant production (ISPP)...

A Polar Traverse Rover (PTR) is a device designed to determine the role of Antarctica in the global climate system by determining typical paths of continental air that passes the South Pole, and by obtaining insight into the relationship between events at the Antarctic and the meteorology of sub- polar altitudes. The...

An acquisition, tracking, and pointing (ATP) system is proposed for aiming an optical- communications downlink laser beam from deep space. In providing for a direction reference, the concept exploits the mature technology of star trackers to eliminate the need for a costly and potentially hazardous...

A document summarizes the development of a carbon-carbon composite radiator for dissipating waste heat from a spacecraft nuclear reactor. The radiator is to be bonded to metal heat pipes and to operate in conjunction with them at a temperature approximately between 500 and 1,000 K. A goal of...

An advanced thrust-measurement system utilizes active magnetic bearings to both (1) levitate a floating frame in all six degrees of freedom and (2) measure the levitation forces between the floating frame and a grounded frame. This system was developed for original use in measuring the...

A generic design for a type of flexible structural- health- monitoring sheet with multiple sensor/actuator types and a method of manufacturing such sheets has been developed. A sheet of this type contains an array of sensing and/or actuation elements, associated wires, and any other associated circuit...

A report describes a rover-type robotic wheeled vehicle recently built for use as a testbed for development of software for future rover-type vehicles. This vehicle is a derivative of the Field Integrated Design and Operations (FIDO) rover, which is a prototype Mars- exploration rover that also serves as a terrestrial...

A modification has been made in the mating halves of a cam-and- groove hose coupling to prevent rapid separation of the halves in the event that the cam levers are released while the fluid in the hose is pressurized. This modification can be duplicated on almost any commercially available cam-and-...

Several modifications have been made to the design and operation of an extended-shaft cryogenic pump to increase the efficiency of pumping. In general, the efficiency of pumping a cryogenic fluid is limited by thermal losses (the thermal energy that the pump adds to the fluid). The sources of the...

G-Sample is designed for sample collection missions to identify the presence and quantity of sample material gathered by spacecraft equipped with end effectors. The software method uses a maximum-likelihood estimator to identify the collected sample's mass based on onboard force-sensor...
