Mechanical & Fluid Systems

A document discusses a heat rejection device for transferring heat from a space vehicle by venting water into space through the use of a novel, two-stage water distribution system. The system consists of two different, porous media that stop water-borne contaminants from clogging the system and causing operational failures.

A document describes the design of a lightweight (between 100 to 200 kg), light-tight shroud of about 3.9 meters in diameter that could be stowed into a very small volume, and be deployed to 12 meters. The shroud will consist of two concentric multi-layer blankets (MLIs) that are constructed...

Microfluidic pumps and valves based on pneumatically actuated diaphragms made of Teflon® AF polymers are being developed for incorporation into laboratory-on-a-chip devices that must perform well over temperature ranges wider than those of prior diaphragm-based microfluidic pumps and valves....

UltraSail is a next- generation ultra-large (km2 class) sail system. Analysis of the launch, deployment, stabilization, and control of these sails shows that high-payload-mass fractions for interplanetary and deep-space missions are possible. UltraSail combines propulsion and control systems developed for formation- flying...

The silicon substrate carrier was created so that a large-area array (in this case 62,000+ elements of a microshutter array) and a variety of discrete passive and active devices could be mounted on a single board, similar to a printed circuit board. However, the density and...

Failure is not an option when it comes to medical equipment. From critical or sensitive devices like lasers, MRI scanners, knee joints, and implantable pacemakers to instruments as straightforward as stethoscopes, when life is at stake, medical equipment must be reliable.

Flow-splitting and flow-mixing thermally actuated spool valves have been developed for controlling flows of a heat-transfer fluid in a temperature-regulation system aboard the Mars Science Laboratory (MSL) rover. Valves like these could also be useful in terrestrial temperature-regulation...

A system has been designed to reduce the hydrogen molecule content in inert gases that are used for shielding the welding arc and molten weld area during the manual fusion, automated welding, and induction brazing process. Two desiccant pipeline dryer cartridges are connected together using either...

A paper describes the Octanode, a connecting node that facilitates the integration of multiple docking mechanisms, hatches, windows, and internal and external systems with the use of flat surfaces. The Octanode is a 26-faced Great Rhombicuboctahedron Archimedean solid with six octagon-shaped panels, eight hexagon-shaped panels, and...

A document proposes that future spacecraft for planetary and space exploration be designed to enable reuse of drained propellant tanks for occupancy by humans. This proposal would enable utilization of volume and mass that would otherwise be unavailable and, in some cases, discarded. Such...

A hammer drill design of a voice coil linear actuator, spring, linear bearings, and a hammer head was proposed. The voice coil actuator moves the hammer head to produce impact to the end of the drill bit. The spring is used to store energy on the retraction and to capture the rebound energy...
