Manufacturing & Prototyping

A technique based on the generation of highly localized thermal stresses has been devised as a means of cutting both flat and curved glass sheets of thicknesses between 30 and 600 µm. The technique is reliable, accurate, and economical. The technique can be used, for example, to cut thin glass...

A method that exploits rapid prototyping has been conceived to reduce the time and cost associated with the production of small quantities of composite-material parts that have complex shapes. In this method, mandrels and dies used in forming composite layups are sized and shaped by...

A mechanical device has been developed for applying an adhesive patch, from the outside, to the wall of a spacecraft module that has lost pressure because of penetration by a meteoroid or a piece of orbital debris. This device will make it possible to seal and re-pressurize the affected module during space...

Experiments have shown that a substrate can be patterned with submicron features by the following procedure:

Outer-space plasmas and arc-jet plasmas are well known to many researchers at NASA. Efforts to understand the structures of these plasmas have consumed years of research at various NASA laboratories. Computational modeling of such plasmas involves analyses of multicomponent,...

Scanning ultraviolet (UV) lasers would be used to expose ultraviolet-sensitive photoresists to form patterns of conductors for electronic circuits, according to a proposal. Heretofore, such patterns have been formed by exposing photoresists to collimated ultraviolet or visible light through...

In a proposed technique of maskless gray-scale x-ray lithography, a photoresist to be patterned would be exposed to a parallel beam of hard x-rays. As explained below, the photoresist would be translated across the beam at a varying rate to effect one-dimensional spatial variations in the radiation dose...

Several improvements have been proposed for the fabrication process known as "rapid prototyping." In this process, a model or prototype of a solid object is built up by controlled ejection of molten polymeric material through programmed orifices to form patterned layers. The second layer is deposited on top of the...

The skirt that supports a composite-overwrapped tank would be made an integral part of the composite overwrap, according to a proposal. In current practice, the structure that supports a composite-overwrap tank usually includes a layer of rubber between the tank and its skirt. The rubber layer...
