Mechanical & Fluid Systems

Rover Analysis, Modeling, and Simulations (ROAMS) is a computer program that simulates the operation of a robotic vehicle (rover) engaged in exploration of a remote planet. ROAMS is a rover-specific extension of the DARTS and Dshell programs, described in prior NASA Tech Briefs articles, which afford...

A paper describes a demonstration of the X-38 bolt-retractor system (BRS) on a spacecraft-simulating apparatus, called the Large Mobility Base, in NASA Flight Robotics Laboratory (FRL). The BRS design was proven safe by testing in NASA Pyrotechnic Shock Facility (PSF) before being demonstrated in...

Aerodynamics and Performance Estimation Toolset is a collection of four software programs for rapidly estimating the preliminary design performance of aerospace vehicles represented by doing simplified calculations based on ballistic trajectories, the ideal rocket equation, and...

A report describes the personal radiation protection system (PRPS), which has been invented for use on the International Space Station and other spacecraft. The PRPS comprises walls that can be erected inside spacecraft, where and when needed, to reduce the amount of radiation to which personnel are...

A short document proposes liquid- metal- fed pulsed plasma thrusters for small spacecraft. The propellant liquid for such a thruster would be a low- melting- temperature metal that would be stored molten in an unpressurized, heated reservoir and would be pumped to the thruster by a magneto- hydrodynamic...

An inlet housing for a partial-admission turbine has been designed to cause the inlet airflow to make a smooth transition from an open circular inlet to an inlet slot. The smooth flow is required for purposes of measuring inlet flow characteristics and maximizing the efficiency of the turbine.

An alternative approach to the design and fabrication of vibratory gyroscopes is founded on the use of fabrication techniques that yield best results in the mesoscopic size range, which is characterized by overall device dimensions of the order of a centimeter. This approach stands in...

A document proposes an improved liquid- ring nutation damper for a spin-stabilized spacecraft. The improvement addresses the problem of accommodating thermal expansion of the damping liquid. Heretofore, the problem has been solved by either (1) filling the ring completely with liquid and...

A proposed design for a solenoid-based electromechanical actuator would provide greater starting force than does a comparable conventional design. As used here, "starting force" signifies the magnetic force exerted by the actuator at one end of its stroke when the gap in its magnetic circuit is the widest. A solenoid of...

A flow straightener has been incorporated into a rotary liquid separator that originally comprised an inlet tube, a shroud plate, an impeller, an inner drum, an outer drum, a housing, a pitot tube, and a hollow shaft motor. As a consequence of the original geometry of the impeller, shroud,...

A proposed design for carabiners (tether hooks used in mountaineering, rock climbing, and rescue) is intended to make it possible to operate these devices even while wearing thick gloves. According to the proposal, the gate of a carabiner would be capable of swinging either toward or away from the hook body,...

A method of determining the amount of fluid in a tank is based on measurement of strains induced in tank supports by the weight of the fluid. Unlike most prior methods, this method is nonintrusive: there is no need to insert instrumentation in the tank and, hence, no need to run wires, cables,...

Expandable ice-prevention and cleanliness-preservation (EIP-CP) chambers have been proposed to prevent the accumulation of ice or airborne particles on quick-disconnect (QD) fittings, or on ducts or tubes that contain cryogenic fluids. In the original application for which the EIP-CP...
